xProduktdetails
| Maximale Prüfhöhe | 160 mm | Abstand zwischen Einzug und Wand | 135 mm |
|---|---|---|---|
| Formgröße | 250 × 550 × 650 mm | Dauer der Gewalt | (5-60) s |
| Verfahren zur Anwendung der Prüfkraft | Automatisch | ||
| Hervorheben | portable brinell hardness tester,rockwell superficial hardness tester |
||
Produkt-Beschreibung
Touch Screen Digital Automatic Tower Light Load Brinell hardness tester MHBS-62.5Z
Introduction
The touch screen digital automatic tower light load Brinell hardness tester MHBS-62.5 is a new Brinell hardness tester using precision mechanical technology and photoelectric technology. The machine is controlled by an embedded microcomputer and is suitable for cast iron, non-ferrous metals and their alloys. All kinds of annealed and tempered steel are particularly suitable for the hardness detection of softer metals such as pure aluminum, lead and tin. It is an ideal Brinell hardness test instrument for scientific research institutions, enterprises and quality inspection departments to conduct research and testing.
Product characteristics
1.Regulation measures the strength of the light source;
2.Real-time display of test ambient temperature;
3.Printing hardness test data, easy to use;
4.High measurement accuracy;
5.Automatic switch the indenter and objective lens
6.Automatic calculate and display the testing value
7.Can select the convert scale according to the material.
8.Unique closed-loop control system, hardness test is faster and more accurate
9.Touch screen control panel.
10.Choose any of six force from 6.25kgf to 70kgf
Technical parameters
| Model | MHBS-62.5Z |
| Force | 61.25N(6.25kgf),98.07N(10kgf),153.2N(15.625kgf), 294N(30kgf),306.25N(31.25kgf),612.9N(62.5kgf) |
| Standard of execution | EN, ISO 6507, EN ISO 6506, ASTM E-384, ASTM E-10-08, ASTM E-384 GB/T231.2,JJG150 |
| Test maximum height | 160mm |
| Indenter to wall distance | 135mm |
| Shape size | 250×550×650mm |
| Force duration time | (5-60) s |
| Test force application method | Automatic |
| Measurement of magnification | 40x,100x |
| Hardness measurement range | 8-650 HBW |
| Power | AC220V/50HZ |
| Weight | 45kg |
Standard Configuration
| Name | Quantity | Name | Quantity |
| Ф1mm Steel ball indenter | 1 | Ф2.5mm Steel ball indenter | 1 |
| Ф5mm Steel ball indenter | 1 | Large, medium, flat, V-shaped platform | 3 |
| Brinell hardness block | 2 | weight | 1 |
| Fuze | 2 | Power wire | 1 |
| description | 1 | Qualification Certificate | 1 |
| Printing paper | 1 |
